Siemens SIMATIC ET 200SP User Manual

Parameters
13.1 Parameters
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
100 Manual, 07/2018, A5E42674880-AA
Parameters
Value range
Default setting
Reconfigu-
ration in
RUN
Limits
Number of limits
• 0 ... 16
0 Yes
Limit monitoring
• Disable
• Enable
Disable Yes
Measured variable
• Measured value ID see Measured value
data records (Page 226)
None Yes
Enable limit monitoring gate
• Disable
• Enable
Disable Yes
Hardware interrupt
• Disable
• Enable
Disable Yes
Limit
• depending on the selected measured
variable
0.0000 Yes
Type
• High limit
• Low limit
High limit Yes
Hysteresis for limit monitoring
[0.1%]
• 0 ... 200 [0.1%]
1% Yes
Delay time for limit monitoring [s]
• None
• 1 ... 10 s
None Yes
User data mapping I/II
Number of measured values
• 0 ... 64
0 Yes
Measured variable
• Measured value ID see Measured varia-
bles (Page 163)
None Yes
Data record mapping
Number of measured values
• 0 ... 150
• 0 ... 125 with STEP 7 (TIA Portal) V15
with HSP0253
0 Yes
Measured variable
• Measured value ID see Measured varia-
bles (Page 163)
None Yes
