Siemens SIMATIC ET 200SP User Manual

Parameters
13.1 Parameters
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
99
Parameters
Value range
Default setting
Reconfigu-
ration in
RUN
Diagnostics
overflow cumulative values
• Disable
• Enable
Disable Yes
Detect voltage swell and dip
• Disable
• Enable
Disable Yes
Detect peak value current
• Disable
• Enable
Disable Yes
Detect peak value voltage
• Disable
• Enable
Disable Yes
Detect overcurrent
• Disable
• Enable
Disable Yes
Analyse harmonics
• Disable
• Enable
Disable Yes
Nominal value current [A]
• 0 ... 99999
1 Yes
Tolerance factor overcurrent in
relation to nominal value current
[0.1%]
• 10 ... 60000
100 Yes
Tolerance time overcurrent [ms]
• 0 ... 60000
40000 Yes
Low limit current measurement
in relation to nominal value cur-
rent [0.1%]
• 0 ... 200
10 Yes
Enable operating hours counter
• Disable
• Enable
Disable Yes
Enable gate of operating hours
counter
• Disable
• Enable
Disable Yes
Current transformer primary
current [A]
• 1 ... 99999 A
1 A Yes
Current transformer secondary
current
• 1 A
• 5 A
1 A Yes
Reverse current direction
• Disabled
• Reverse current direction
Disabled Yes
Nominal value voltage [V]
• 1 ... 999999
230 V Yes
Tolerance factor overvolt-
age/undervoltage [0.1%]
• 10 ... 500
100 Yes
Voltage transformer primary
voltage [V]
• 1 ... 999999 V
230 V Yes
Voltage transformer secondary
voltage [V]
• 1 ... 500 V
230 V Yes
