Siemens SIMATIC ET 200SP User Manual

Parameters
13.1 Parameters
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
98 Manual, 07/2018, A5E42674880-AA
Parameters
Value range
Default setting
Reconfigu-
ration in
RUN
End value energy meter
• No end value (infinite counting)
• Count periodically to 10
3
• Count periodically to 10
6
• Count periodically to 10
9
• Count periodically to 10
12
• Count periodically to 10
15
No end value (infinite
counting)
Yes
User data variant See the table Overview of the user data
variants (Page 205)
Total power L1L2L3
(W#16#FE)
Yes
Minimum and maximum value
calculation
• Disable
• Enable
Disable Yes
Minimum and maximum value
calculation gate
• Disable
• Enable
Disable Yes
Power quality analysis functions
• Disable
• Enable
Disable Yes
Residual current analysis
• Disable
• Enable
Disable Yes
Neutral: Current transformer
primary current [A]
• 0 = Disabled
• 1 ... 99999 = measuring
• 4294967295 = Calculating
0 Yes
Neutral: Current transformer
secondary current [A]
• 1
• 5
1 Yes
Voltage dip limit value in relation
to nominal value voltage [0.1%]
• 10 ... 1000
100 Yes
Voltage swell limit value in rela-
tion to nominal value voltage
[0.1%]
• 10 ... 10000
100 Yes
Threshold overcurrent in relation
to nominal value current [0.1%]
• 10 ... 60000
100 Yes
Number of cycles for voltage
swell and dip analysis
• 4 ... 32767
10 Yes
Diagnostics power quality
• Disable
• Enable
Disable Yes
Diagnostics
overflow current
• Disable
• Enable
Disable Yes
Diagnostics
overflow voltage
• Disable
• Enable
Disable Yes
Diagnostics
underflow voltage
• Disable
• Enable
Disable Yes
