Parameters
13.1 Parameters
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
97
The following table summarizes all the configurable parameters with STEP 7 (GSD file).
Table 13- 1 Parameters AI Energy Meter HF (GSD file)
Parameters
Value range
Default setting
Reconfigu-
ration in
RUN
Hardware interrupt
• Disable
• Enable
Disable No
Inputs
Diagnostics: Missing supply
voltage L+
• Disable
• Enable
Disable Yes
Connection type
• Disabled
• 1P2W - 1 phase, 2 conductors
• 3P4W - 3 phase current measurement, 4
conductors
• 3P4W1, 3 phases, 4 conductors, bal-
anced load
• 3P4W - 3 phases, 4 conductors
• 3x1P2W - 3 x 1 phase, 2 conductors
each
• 2P3W - 2 phases, 3 conductors
• 3P3W, 3 phases, 3 conductors
• 3P3W1, 3 phases, 3 conductors, bal-
anced load
3P4W - 3 phases, 4 con-
ductors
Yes
Voltage measuring range
• 100 V
• 110 V
• 115 V
• 120 V
• 127 V
• 190 V
• 200 V
• 208 V
• 220 V
• 230 V
• 240 V
• 277 V
230 V Yes
Line frequency
• 50 Hz
• 60 Hz
50 Hz Yes
Energy meter gate enabled
• Disable
• Enable
Disable Yes
