Siemens SIMATIC ET 200SP User Manual

Parameter data records
A.5 Structure of the parameter data record 135 for data record mapping
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
161
Parameter block for data record mapping
The following diagram shows the structure of the parameter blocks for data record mapping.
Figure A-17 Parameter block for data record mapping
Data record length DS 135 and DS151
The table below shows the data record lengths of the parameter data record DS 135 and the
user-defined data record DS 151 (Page 258).
The length of the data records depends on the number and the format of the measured
values.
Number
Measured values
Data record length in bytes
REAL measured values
LREAL measured values
DS 135
DS 151
DS 151
29
62
118
234
30
64
122
242 *
40
84
162
322 *
50
104
202
402 *
59
122
238
474 *
100
204
402 *
802 *
118
240
474 *
946 *
150
304*
602 *
1202 *
* not with PROFIBUS DP

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
