Parameter data records
A.5 Structure of the parameter data record 135 for data record mapping
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
162 Manual, 07/2018, A5E42674880-AA
Error while transferring the data record
The module always checks all the values of the transferred data record. Only if all the values
were transferred without errors does the module apply the values from the data record.
The WRREC instruction for writing data records returns corresponding error codes when
errors occur in the STATUS parameter.
The following table shows the module-specific error codes and their meaning for the
parameter data record 130/131/135.
Error code in STATUS parameter
(hexadecimal)
Meaning
Solution
Byte 0
Byte 1
Byte 2
Byte 3
DF 80 B0 00 Number of the data record unknown Enter a valid number for the data
record.
DF 80 B1 01 Length of the data record incorrect Enter a valid value for the data record
length.
DF 80 B2 00 Slot invalid or cannot be accessed. Check the station whether the mod-
ule is plugged or drawn.
Check the assigned values for the
parameters of the WRREC instruction
DF
80
E0
01
Incorrect version
Check Byte 0. Enter valid values.
DF 80 E0 02 Error in the header information Check Bytes 1 and 2. Correct the
length and number of the parameter
blocks.
DF 80 E1 01 Reserved bits are not 0. Check Byte 3 and set reserved bits
back to 0.
DF 80 E1 21 "User data variant" not possible or input
data configuration not large enough
Select a different user data variant or
change the configuration.
DF 80 E1 30 Data record number invalid Check the data record number. Enter
a valid data record number.
DF
80
E1
31
"Length of the parameter block" invalid.
Check Byte 1. Length = 10 bytes
DF
80
E1
32
"Number of parameter blocks" invalid.
Check Byte 2. Enter valid values.
DF 80 E1 33 "ID of the measured value for limit monitor-
ing" invalid.
Check Bytes 4 and 5. Enter valid
values.
Measured variables for data record mapping
You can find the measured variables under Measured variables (Page 163). The following
measured variables are not available to you for data record mapping:
● 220 to 226
● 62110 to 62116
● 62210 to 62216
● 62310 to 62316
