Siemens SIMATIC ET 200SP User Manual

Measured variables
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
164 Manual, 07/2018, A5E42674880-AA
Meas-
ured
value
ID
Measured variables
Data
type
Unit
Value range
Connection type
1P
2W
2P
3W
3x
1P2W
3P
4W
3P
4W1
3P
3W
3P
3W1
3P
4WI
23 Reactive power Qtot
L2
3
REAL var -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓
24 Reactive power Qtot
L3
3
REAL var -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓
30
Frequency
4
REAL
Hz
45.0 ... 65.0
✓
✓
✓
✓
✓
✓
✓
✓
31 Average voltage L-N
(U
sum
)
12
REAL V 0.0 ... 300.0 ✓ ✓ ✓ ✓ ✓ ✓ ✓
32
Average voltage L-L
12
REAL
V
0.0 ... 600.0
✓
✓
✓
✓
33 Average current
L1L2L3 (I
sum
)
12
REAL A 0.0 ... 100000.0 ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
34 Total active power
L1L2L3
5
REAL W -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
35 Total reactive power
L1L2L3
5
REAL var -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
36 Total apparent power
L1L2L3
5
REAL VA -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
37 Total power factor
L1L2L3
6
REAL - 0.0 ... 1.0 ✓ ✓ ✓ ✓ ✓ ✓ ✓
38 Reactive power Qtot
L1L2L3
3 5
REAL var -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
40
Max. voltage UL1-N
14
REAL
V
0.0 ... 300.0
✓
✓
✓
✓
✓
✓
✓
41
Max. voltage UL2-N
14
REAL
V
0.0 ... 300.0
✓
✓
✓
✓
✓
✓
42
Max. voltage UL3-N
14
REAL
V
0.0 ... 300.0
✓
✓
✓
✓
✓
43 Max. voltage UL1-UL2
14
REAL V 0.0 ... 600.0 ✓ ✓ ✓ ✓ ✓
44 Max. voltage UL2-UL3
14
REAL V 0.0 ... 600.0 ✓ ✓ ✓ ✓
45 Max. voltage UL3-UL1
14
REAL V 0.0 ... 600.0 ✓ ✓ ✓ ✓
46
Max. current L1
14
REAL
A
0.0 ... 100000.0
✓
✓
✓
✓
✓
✓
✓
✓
47
Max. current L2
14
REAL
A
0.0 ... 100000.0
✓
✓
✓
✓
✓
✓
✓
48
Max. current L3
14
REAL
A
0.0 ... 100000.0
✓
✓
✓
✓
✓
✓
49 Max. apparent power
L1
14
REAL VA -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
50 Max. apparent power
L2
14
REAL VA -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓
51 Max. apparent power
L3
14
REAL VA -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓
52 Max. active power L1
14
REAL W -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
53 Max. active power L2
14
REAL W -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓
54 Max. active power L3
14
REAL W -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓
