Siemens SIMATIC ET 200SP User Manual

Measured variables
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
165
Meas-
ured
value
ID
Measured variables
Data
type
Unit
Value range
Connection type
1P
2W
2P
3W
3x
1P2W
3P
4W
3P
4W1
3P
3W
3P
3W1
3P
4WI
55 Max. reactive power L1
14
REAL var -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
56 Max. reactive power L2
14
REAL var -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓
57 Max. reactive power L3
14
REAL var -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓
58 Max. power factor L1
14
REAL - 0.0 ... 1.0 ✓ ✓ ✓ ✓ ✓ ✓ ✓
59 Max. power factor L2
14
REAL - 0.0 ... 1.0 ✓ ✓ ✓ ✓ ✓ ✓
60 Max. power factor L3
14
REAL - 0.0 ... 1.0 ✓ ✓ ✓ ✓ ✓
61
Max. frequency
14
REAL
Hz
45.0 ... 65.0
✓
✓
✓
✓
✓
✓
✓
✓
62 Max. mean voltage L-N
14
REAL V 0.0 ... 300.0 ✓ ✓ ✓ ✓ ✓
63 Max. mean voltage L-L
14
REAL V 0.0 ... 600.0 ✓ ✓ ✓ ✓
64 Max. mean current
L1L2L3
14
REAL A 0.0 … 100000.0 ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
65 Max. active power
L1L2L3
14
REAL W -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
66 Max. reactive power
Qn L1L2L3
14
REAL var -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
67 Max. apparent power
L1L2L3
14
REAL VA -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
68 Max. total power factor
14
REAL - 0.0 ... 1.0 ✓ ✓ ✓ ✓ ✓ ✓ ✓
70
Min. voltage UL1-N
14
REAL
V
0.0 ... 300.0
✓
✓
✓
✓
✓
✓
✓
71
Min. voltage UL2-N
14
REAL
V
0.0 ... 300.0
✓
✓
✓
✓
✓
✓
72
Min. voltage UL3-N
14
REAL
V
0.0 ... 300.0
✓
✓
✓
✓
✓
73 Min. voltage UL1-UL2
14
REAL V 0.0 ... 600.0 ✓ ✓ ✓ ✓ ✓
74 Min. voltage UL2-UL3
14
REAL V 0.0 ... 600.0 ✓ ✓ ✓ ✓
75 Min. voltage UL3-UL1
14
REAL V 0.0 ... 600.0 ✓ ✓ ✓ ✓
76
Min. current L1
14
REAL
A
0.0 ... 100000.0
✓
✓
✓
✓
✓
✓
✓
✓
77
Min. current L2
14
REAL
A
0.0 ... 100000.0
✓
✓
✓
✓
✓
✓
✓
78
Min. current L3
14
REAL
A
0.0 ... 100000.0
✓
✓
✓
✓
✓
✓
79 Min. apparent power
L1
14
REAL VA -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓ ✓
80 Min. apparent power
L2
14
REAL VA -3.0e+9 … +3.0e+9 ✓ ✓ ✓ ✓ ✓ ✓
