Module versions
C.2 Module version "32 I / 20 Q"
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
197
Structure of output user data
The structure of the output user data is fixed and is the same at all the selectable user data
variants.
Via the output user data you control globally or phase-specifically
● Resetting for minimum values, maximum values, limits, operating hours counter and
energy meters.
● The counter gates for operating hours counter and energy counters.
● Gate for limits, minimum values and maximum values.
Table C- 4 Structure of output user data (20 bytes)
0 Module User data vari-
Control byte for switching the user data variant
1 Module Control byte 1 Global resetting of values and counters, gate
Selection of the energy counter to be reset
3 Module Control byte 3 Control of the limit monitoring of limit values 9 to 16
Control of the limit monitoring of limit values 1 to 8
Phase-specific resetting of values and counters, gate for Phase L1
Phase-specific resetting of values and counters, gate for Phase L2
Phase-specific resetting of values and counters, gate for Phase L3
12 Module and phas-
Control byte 12 Deletion of power quality analysis results or starting/stopping the
16 Module and phas-
Control byte 16 General reset (Page 41)
