Siemens SIMATIC ET 200SP User Manual

User data variants
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
Manual, 07/2018, A5E42674880-AA
217
Basic variables energy counter measurement (periodic) overflow counter (ID 239 or EF
H
)
Table D- 14 Basic variables energy counter measurement (periodic) overflow counter
Byte
Allocation
Data
type
Unit
Value range
Meas-
ured
value
ID
0
User data variant
BYTE
-
239 (EFH)
-
1 Quality information = QQ
1
I
3
U
3
I
2
U
2
I
1
U
1
BYTE Bit
string
qq xx xx xx -
2 ... 3
Overflow counter for active energy inflow L1
UINT
-
0 … 65535
62120
4 ... 5 Overflow counter for active energy outflow L1 UINT - 0 … 65535 62121
6 ... 7
Overflow counter for reactive energy inflow L1
UINT
-
0 … 65535
62122
8 ... 9
Overflow counter for reactive energy outflow L1
UINT
-
0 … 65535
62123
10 ... 11
Overflow counter for apparent energy L1
UINT
-
0 … 65535
62124
12 ... 13
Overflow counter for active energy inflow L2
UINT
-
0 … 65535
62220
14 ... 15
Overflow counter for active energy outflow L2
UINT
-
0 … 65535
62221
16 ... 17
Overflow counter for reactive energy inflow L2
UINT
-
0 … 65535
62222
18 ... 19
Overflow counter for reactive energy outflow L2
UINT
-
0 … 65535
62223
20 ... 21
Overflow counter for apparent energy L2
UINT
-
0 … 65535
62224
22 ... 23
Overflow counter for active energy inflow L3
UINT
-
0 … 65535
62320
24 ... 25
Overflow counter for active energy outflow L3
UINT
-
0 … 65535
62321
26 ... 27
Overflow counter for reactive energy inflow L3
UINT
-
0 … 65535
62322
28 ... 29
Overflow counter for reactive energy outflow L3
UINT
-
0 … 65535
62323
30 ... 31
Overflow counter for apparent energy L3
UINT
-
0 … 65535
62324
