Siemens SIMATIC ET 200SP User Manual

User data variants
Analog input module AI Energy Meter 480VAC/CT HF (6ES7134-6PA00-0CU0)
218 Manual, 07/2018, A5E42674880-AA
Basic variables measurement data profile (ID 227 or E3
H
)
Table D- 15 Basic variables measurement data profile Energy E3
Byte
Allocation
Data
type
Unit
Value range
Meas-
ured
value
ID
0
User data variant
BYTE
-
227 (E3
H
)
-
1 Quality information = QQ
1
I
3
U
3
I
2
U
2
I
1
U
1
BYTE Bit
string
qq xx xx xx -
2 ... 5
Active power L1
REAL
1 W
-3 x 10
9
... +3 x 10
9
13
6 ... 9 Active power L2 REAL 1 W -3 x 10
9
... +3 x 10
9
14
10 ... 13
Active power L3
REAL
1 W
-3 x 10
9
... +3 x 10
9
15
14 ... 17
Reactive power Qtot L1
REAL
1 var
-3 x 10
9
... +3 x 10
9
22
18 ... 21
Reactive power Qtot L2
REAL
1 var
-3 x 10
9
... +3 x 10
9
23
22 ... 25
Reactive power Qtot L3
REAL
1 var
-3 x 10
9
... +3 x 10
9
24
26 ... 33
Total active energy L1L2L3 inflow
LREAL
1 Wh
0.0 ... 1.8 x 10
308
210
34 ... 41
Total active energy L1L2L3 outflow
LREAL
1 Wh
0.0 ... 1.8 x 10
308
211
42 ... 49
Total reactive energy L1L2L3 inflow
LREAL
1 varh
0.0 ... 1.8 x 10
308
212
50 ... 57
Total reactive energy L1L2L3 outflow
LREAL
1 varh
0.0 ... 1.8 x 10
308
213
58 ... 61
Voltage UL1-N
REAL
1 V
0.0 … 1000000.0
1
62 ... 65
Voltage UL2-N
REAL
1 V
0.0 … 1000000.0
2
66 ... 69
Voltage UL3-N
REAL
1 V
0.0 … 1000000.0
3
70 ... 73
Voltage UL1-UL2
REAL
1 V
0.0 … 1000000.0
4
74 ... 77
Voltage UL2-UL3
REAL
1 V
0.0 … 1000000.0
5
78 ... 81
Voltage UL3-UL1
REAL
1 V
0.0 … 1000000.0
6
82 ... 85
Current L1
REAL
1 A
0.0 … 100000.0
7
86 ... 89
Current L2
REAL
1 A
0.0 … 100000.0
8
90 ... 93
Current L3
REAL
1 A
0.0 … 100000.0
9
94 ... 97
Power factor L1
REAL
-
0.0 … 1.0
19
98 ... 101 Power factor L2 REAL - 0.0 … 1.0 20
102 ...
105
Power factor L3 REAL - 0.0 … 1.0 21

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
