Detailed descriptions
16.4 BIOS-Setup
SIMATIC HMI IPC677C
230 Operating Instructions, 04/2013, A5E02722710-04
Entry Meaning
IGD Dual View DVI/CRT Activate/deactivate the dual view mode: Simultaneous operation
of 2 monitors (CRT and DVI) by means of adapter (splitter) at
the DVI output of the device.
IGD Dual View VGA DDC Enabled: When a DVI monitor and a CRT monitor are operated
via a Y cable, the DDC signal of the DVI monitor is also used for
the CRT monitor. This prevents the CRT monitor screen briefly
going black when you right-click.
The CRT monitor resolution should be the same or higher than
that of the DVI monitor.
Advanced menu > USB Configuration
Figure 16-10 Submenu Advanced menu > USB Configuration
Entry Meaning
USB Port0 -10
• Enable: USB port is activated.
• Auto: USB port is deactivated when no device is plugged.
• Disable: USB port is deactivated.
