Detailed descriptions
16.4 BIOS-Setup
SIMATIC HMI IPC677C
Operating Instructions, 04/2013, A5E02722710-04
229
Advanced menu > Video Configuration
Figure 16-9 Submenu Advanced menu > Video Configuration
Entry Meaning
Primary video device Selection of the primary video interface to which the boot
messages are to be output:
• IGD: Internal onboard graphics
• PEG: PCIExpress graphics (internal graphics is deactivated)
• PCI: PCI graphics (internal graphics is deactivated)
IGD boot type Selection of the video device that is used during booting.
• Auto: The graphics specified by the VIDEO BIOS is used.
• CRT: VGA screen
• LFP: Local Flat Panel
• CRT+LFP: VGA screen and local display
Forced CRT Enabled: The CRT/VGA interface is active even when no
monitor is connected, e.g. for AMT headless mode.
Disabled: The CRT/VGA interface is only active when a monitor
is connected.
