Siemens SIMATIC HMI series System Manual

Dropdown texts
Some pages of the online help features headings underlined in blue. Click these headings to
call up drop-down texts.
The additional
information consists of text, tables, etc. To hide the drop-down text, click it again.
The following notation is used in the online help:
Icon Meaning
Heading with this form indicate expandable text in
the online help.
Use the menu commands "Tools > Open" or "Close" to open or close all drop-down texts of a
page at once.
Print versions of the WinCC Information System
The help provided in the WinCC Information System can also be printed.
You can
find the main chapters of the WinCC Information System as PDF files via the Windows
Start menu "Start > Simatic > WinCC > WinCC Information System". To open these files, you
will need Adobe Acrobat Reader.
You can download the Adobe Acrobat Reader free of charge from the following URL:
● http://www.adobe.com/products/acrobat (
http://www.adobe.com/products/acrobat)
The PDF files of the online help are also included on the WinCC product DVD in the
"Documents" directory.
Service and Support
4.4 Help on WinCC Documentation
WinCC: General information and installation
System Manual, 02/2017, A5E40840020-AA 127
