6.2 Starting ApDiag.exe
Start ApDiag
Apdiag.exe is located in the installation directory in folder "...\Siemens\WinCC\Utools".
As soon as WinCC is opened, you can start the application as usual (double click). It is
irrelevant whether
runtime is activated or not. If no project has been opened, a link to the action
controller can be created.
ApDiag is ended when changing projects and when closing WinCC.
To permanently display diagnostics information, independent of operation and navigation in
the system, ApDiag is in the foreground. Set your window position and size so that ApDiag
disturbs as little as possible. These settings are saved and reestablished again during the next
startup.
WinCC diagnosis
6.2 Starting ApDiag.exe
WinCC: General information and installation
164 System Manual, 02/2017, A5E40840020-AA
