8.3 Graphics System
Configuration
Observe the following restrictions:
●
The number and complexity of the objects used affect the performance.
●
PDL files larger than 100 MB are not displayed in WinCC Runtime.
● The performance data can be limited by system resources.
Maximum
Objects per picture No limit
Levels per picture 32
Pictures (PDL files) per project No limit
Instances of fixed faceplates in a process picture 31 instances of the same
type picture
Picture size in pixels 10 000 x 10 000
Nesting levels of picture objects 20
Number of colors Dependent on graphics card
Runtime
The performance data depends on the hardware implemented.
Process pictures with the following values were tested as typical scenario:
Change picture from empty screen to... Time, in seconds
Picture with standard objects (100 objects) 1
Picture with 2 480 I/O fields (8 internal tags) 1
Picture with 1 000 I/O fields (1 000 internal tags) 1
Picture of 10 MByte size (bitmap) 1
Message window 2
Table with 4 columns, each with 120 values
1)
1
1) The specified values apply to data from "Tag Logging Fast".
Note
Notes on configuration for WinCC projects
Observe the notes on "Configurations > Multi-User Systems > Quantity Structures and
Performance"
Performance Data
8.3 Graphics System
WinCC: General information and installation
System Manual, 02/2017, A5E40840020-AA 211
