7.6
Count
ers
S7
-
200 SMART
System Manual
,
V2.3, 07/2017
,
A5E03822230
-
AF
255
Example CTD count down
LAD
STL
Count down c
ounter C1
current val
ue
counts fr
om 3 to 0
With I0.1 OFF, I0.0
OFF
-
ON dec
r
e-
ments C1
current valu
e
I0.1 ON lo
ads countdow
n preset va
lue
3
Network 1
LD I0.0
LD I0.1
CTD C1, +3
C1 bit is ON
when count
er C1 curren
t
value = 0
Network 2
LD C1
= Q0.0
Timing diagr
am
254
256
