Program i
nstruc
tions
7.6
Count
ers
S7
-
200 SMART
256
System Manual
,
V2.3, 07/2017
,
A5E03822230
-
AF
Example CTUD count up/down
LAD
STL
I0.0 counts up
I0.1 counts down
I0.2 reset
s current va
lue to 0
Network 1
LD I0.0
LD I0.1
LD I0.2
CTUD C48, +4
Count Up/Dow
n counter
C48 turns on
C48 bit when current valu
e
>=
4
Network 2
LD C48
= Q0.0
Timing diagr
am
255
257
