Siemens SIMATIC TeleControl DNP3 User Manual

Configuration
3.20 Configuring data points
Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01
127
Table 3- 6 Decoding of the control code by the command data point of the station
Received control code
Reaction of the station data point
Control
Code
Trip-
Close
Code
Operation
Type Field
Option enabled:
PULSE_ON
Option enabled:
LATCH_ON / OFF
0x01 NUL PULSE_ON The output is set to 1 for the
duration of "On-time".
The command is rejected.
0x03 NUL LATCH_ON
• CP
The command is rejected.
• TIM 1531 IRC
The output is set to 1 for the
duration of "On-time".
The output is set to 1.
0x04 NUL LATCH_OFF
• CP
The command is rejected.
• TIM 1531 IRC
The output is set to 1 for the
duration of "On-time".
The output is set to 0.
0x41 CLOSE PULSE_ON
• CP
The command is rejected.
• TIM 1531 IRC
The output is set to 1 for the
duration of "On-time".
• CP
The command is rejected.
• TIM 1531 IRC
The output is set to 1.
0x81 TRIP PULSE_ON
• CP
The command is rejected.
• TIM 1531 IRC
The output is set to 1 for the
duration of "On-time".
• CP
The command is rejected.
• TIM 1531 IRC
The output is set to 0.
Note
Mirroring
If you want the station data point to mirror the current val
ue back to the master, enable the
"Value monitoring" option in the "General" tab of the data point.
Selection of the control code
Name:
Control Code
Range of va
l-
ues:
•
PULSE_ON
•
LATCH_ON/OFF
Explanation:
Output option of the command output. See above for the meaning.
Select the desired output option.
