Siemens SIMATIC TIM 3V-IE DNP3 - Page 179

The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
179
Data object
Object type and function
Number of
indexes
occupied
DNP3 object group [vari-
ation]
(S7 data type)
DNP3 level *
Use in stations
type **
Mean04W_S
Mean value object for send
direction
Send 4 mean values (16-bit
value)
4
• 30 [2] (WORD)
• 32 [2] (WORD)
• 32 [4] (WORD)
• 41 [2] (WORD)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• S
• S
• S
• M
Mean04W_R
Mean value object for receive
direction
Receive 4 mean values (16-bit
value)
4
• 30 [2] (WORD)
• 32 [2] (WORD)
• 32 [4] (WORD)
• 41 [2] (WORD)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• M
• M
• M
• S
Counted value objects
Cnt01D_S
Counted value object for send
direction
Send 1 counted value
1
• 20 [2] (WORD)
• 21 [2] (WORD)
• 21 [6] (WORD)
• 22 [2] (WORD)
• 22 [6] (WORD)
• 23 [2] (WORD)
• 1 ... 5
• 1 ... 4
• 5
• 1 ... 4
• 5
• 1 ... 5
S
Cnt01D_R
Counted value object for re-
ceive direction
Receive 1 counted value
1
• 20 [2] (WORD)
• 22 [2] (WORD)
• 22 [6] (WORD)
• 1 ... 5
• 1 ... 4
• 5
M
Cnt04D_S
Counted value object for send
direction
Send 4 x 1 counted value
4
• 20 [2] (WORD)
• 21 [2] (WORD)
• 21 [6] (WORD)
• 22 [2] (WORD)
• 22 [6] (WORD)
• 1 ... 5
• 1 ... 4
• 5
• 1 ... 4
• 5
S
Cnt04D_R
Counted value object for re-
ceive direction
Receive 4 x 1 counted value
4
• 20 [2] (WORD)
• 22 [2] (WORD)
• 22 [6] (WORD)
• 1 ... 5
• 1 ... 4
• 5
M
Command objects
Cmd01B_S
Command object for send di-
rection
Send 1 command (1 bit)
1
• 1 [2] (BYTE)
• 2 [2] (BYTE)
• 12 [1] (BYTE)
****
1 ... 5
• S
• S
• M
Cmd01B_R
Command object for receive
direction
Receive 1 command (1 bit)
1
• 1 [2] (BYTE)
• 2 [2] (BYTE)
• 10 [2] (BYTE)
• 12 [1] (BYTE)
1 ... 5
• M
• M
• M
• S
DNP3_Cmd0
1X_R
Command object for receive
direction
Receive 1 command (1 bit)
(with mirroring back function)
1
• 12 [1] (BOOL)
1 ... 5 S
