The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
180 System Manual, 12/2015, C79000-G8976-C253-04
Data object
Object type and function
Number of
indexes
occupied
DNP3 object group [vari-
ation]
(S7 data type)
DNP3 level *
Use in stations
type **
Setpoint and parameter objects
Set01W_S
Setpoint object for send direc-
tion
Send 1 setpoint (16 bits), object
with 3 channels:
• "LocalOperation"
- not used -
• "ReturnedSetpoint"
Function: Mirrored back
setpoint
Channel type: Data receive
1
• 40 [2] (WORD)
***
• 42 [4] (WORD)
***
• 1 ... 5
• 4 ... 5
M
• "SetpointInput"
Function: Setpoint input
Channel type: Setpoint
send
1
• 41 [2] (WORD)
****
• 1 ... 5
Set01W_R
Setpoint object for receive
direction
Receive 1 setpoint (16 bits),
object with 3 channels:
• "Local"
- not used -
• "LocalSetpointInput"
Function: Local setpoint
Channel type: Data send
1
• 40 [2] (WORD)
***
• 42 [4] (WORD)
***
• 1 ... 5
• 4 ... 5
S
• "SetpointOutput"
Function: Setpoint output
Channel type: Setpoint re-
ceive
1
• 41 [2] (WORD) • 1 ... 5
Par12D_S
Parameter object for send
direction
Send max. 12 double words
with parameters or setpoints,
object with 3 channels:
• "LocalOperation"
- not used -
• "ReturnedParameter"
Function: Returned parame-
ter
Channel type: Data receive
1 ... 12
• 40 [1] (DINT)
***
• 42 [3] (DINT)
***
• 1 ... 5
• 4 ... 5
M
• "ParameterInput"
Function: Parameter input
Channel type: Setpoint
send
1 ... 12
• 41 [1] (DINT)
****
• 1 ... 5
