Siemens SIMATIC TIM 3V-IE DNP3 User Manual

The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
181
Data object
Object type and function
Number of
indexes
occupied
DNP3 object group [vari-
ation]
(S7 data type)
DNP3 level *
Use in stations
type **
Par12D_R
Parameter object for receive
direction
Receive max. 12 double words
with parameters or setpoints,
object with 3 channels:
• "Local"
- not used -
• "LocalParameterInput"
Function: Local parameters
Channel type: Data send
1 ... 12
• 40 [1] (DINT)
***
• 42 [3] (DINT)
***
• 1 ... 5
• 4 ... 5
S
• "ParameterOutput"
Function: Parameter output
Channel type: Setpoint re-
ceive
1 ... 12
• 41 [1] (DINT) • 1 ... 5
Universal data objects
Dat12D_S
Data object for send direction
Send max. 12 double words (at
least 1 double word) with any
information
1 ... 12
• 30 [1] (DINT)
• 30 [5] (REAL)
• 32 [1] (DINT)
• 32 [3] (DINT)
• 32 [7] (REAL)
• 41 [1] (DINT)
• 41 [3] (REAL)
• 1 ... 5
• 5
• 1 ... 3
• 4 ... 5
• 5
• 1 ... 5
• 5
• S
• S
• S
• S
• S
• M
• M
2 ... 24
• 30 [2] (INT, WORD)
• 32 [2] (INT, WORD)
• 32 [4] (INT, WORD)
• 41 [2] (INT, WORD)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• S
• S
• S
• M
4 ... 48
• 30 [2] (BYTE)
• 32 [2] (BYTE)
• 32 [4] (BYTE)
• 41 [2] (BYTE)
• 110 [1..255] (CHAR)
• 111 [1..255] (CHAR)
• 1 ... 5
• 1 ... 3
• 4 ... 5
• 1 ... 5
• 1 ... 5
• 1 ... 5
• S
• S
• S
• M
• M / S
• S
