Siemens SIMATIC TIM 3V-IE DNP3 - Page 285

Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
285
Event ID
(hex)
Detailed
event
(hex)
Meaning
F260
Exiting state: Internal / external WAN interface: Subscriber call in main cycle.
F360 030F Entering state: Internal / external WAN interface: Permanent call to a subscriber enabled.
F260
Exiting state: Internal / external WAN interface: Permanent call to a subscriber ended.
F360
0310
Entering state: Internal / external WAN interface: Lack of resources on a subscriber.
F260
Exiting state: Internal / external WAN interface: Lack of resources on a subscriber eliminated.
F360
0311
Entering state: Internal / external WAN interface: Alternative path changeover on.
F260
Exiting state: Internal / external WAN interface: Alternative path changeover off.
F560
0312
Internal / external WAN interface: No message memory available for new image element.
F560
0313
Internal / external WAN interface: Image element too large for image memory.
F560
0314
Internal / external WAN interface: Set number of subscribers exceeded in image.
F560
0316
Internal / external WAN interface: 'List of Active Stations' (LAS) not available.
F560
0317
Internal / external WAN interface: Error receiving a message.
F560
0318
Internal / external WAN interface: Error enabling message memory.
F560 0319 Entering state: Internal / external WAN interface: Communication with AMPLUS-L task dis-
rupted.
F460
Exiting state: Internal / external WAN interface: Communication with AMPLUS-L task OK.
F560
031A
Entering state: Internal / external WAN interface: Communication with clock driver disrupted.
F460
Exiting state: Internal / external WAN interface: Communication with clock driver OK.
F560
031B
Entering state: Internal / external WAN interface: Communication with routing task disrupted.
F460
Exiting state: Internal / external WAN interface: Communication with routing task OK.
F560
031C
Internal / external WAN interface: Modem command invalid.
F560 031D Internal / external WAN interface: Invalid dialing string or bad call number transferred to mo-
dem when calling a subscriber.
F960
031E
Internal / external WAN interface: Incorrect handshake PDU received from a subscriber.
F360
031F
Internal / external WAN interface: Own telephone connection occupied.
F960
0320
Internal / external WAN interface: Modem not replying.
F960
0321
Internal / external WAN interface: Access to called subscriber not permitted.
F960
0322
Internal / external WAN interface: No answer tone received from modem of called subscriber.
F960
0323
Internal / external WAN interface: Called subscriber is not operational.
F960
0324
Internal / external WAN interface: Modem of called subscriber has no power.
F960
0325
Internal / external WAN interface: Telephone line is disrupted.
F360
0326
Internal / external WAN interface: Supervision time exceeded. Repetition starting.
F360 0327 Internal / external WAN interface: All attempts to dial a subscriber were executed. No connec-
tion was established.
F360 0328 Entering state: Internal / external WAN interface: Telephone number list with telephone num-
ber(s) of a subscriber deactivated.
F260 Exiting state: Internal / external WAN interface: Telephone number list with telephone num-
ber(s) of a subscriber activated.
F560 0329 Internal / external WAN interface: Telephone number list with telephone number(s) of a sub-
scriber is invalid or disrupted.
F360
032A
Internal / external WAN interface: Telephone number of a subscriber temporarily disabled.
F360
032B
Internal / external WAN interface: Telephone number of a subscriber was changed.
