7.1 Phasor Measurement Unit (PMU)
61Digital Fault Recorder, SIMEAS R-PMU, Manual
E50417-H1076-C360-A5, Release 10.2012
Table 7-6 TCP transmission via LAN:
Data transfer rate depending on the configuration and reporting rate in kbit/s,
data format 16 bit integer
Configuration Type Reporting rate (Hz)
10 12 15 20 25 30 50 60
1 AC DAU Positive-sequence system 6 7 8 11 14 17 28 34
1 AC DAU Phasors 8 9 111519233845
2 AC DAUs Positive-sequence system 7 8 10 14 17 21 34 41
2 AC DAUs Phasors 1113162127325364
4 AC DAUs Positive-sequence system 9 11 14 19 23 28 47 56
4 AC DAUs Phasors 17202534425184101
1 DDAU Process values 6 8 9 13 16 19 31 38
2 DDAUs Process values 8 10 12 16 20 24 41 49
1 BDAU Binary values 5 6 8 10 13 15 26 31
2 AC DAUs
2 DDAUs
Positive-sequence system/
process values
12 14 18 24 30 36 59 71
2 AC-DAUs
1 DDAU
1 BDAU
Phasors /
process values /
binary values
13 16 20 27 33 40 66 80
