Siemens SIMEAS R User Manual

7
7.1 Phasor Measurement Unit (PMU)
60 Digital Fault Recorder, SIMEAS R-PMU, Manual
E50417-H1076-C360-A5, Release 10.2012
Table 7-5 UDP transmission via LAN:
Data transfer rate depending on the configuration and reporting rate in kbit/s,
data format 32 bit float
Configuration Type Reporting rate (Hz)
10 12 15 20 25 30 50 60
1 AC DAU Positive-sequence system 6 7 8 11 14 17 28 34
1 AC DAU Phasors 9 11 14 19 23 28 47 56
2 AC DAUs Positive-sequence system 8 9 12 16 20 23 39 47
2 AC DAUs Phasors 1518233138467792
4 AC DAUs Positive-sequence system 12 15 18 24 30 37 61 73
4 AC DAUs Phasors 273341546882136163
1 DDAU Process values 7 8 10 14 17 21 34 41
2 DDAUs Process values 10 12 15 21 26 31 52 62
1 BDAU Binary values 5 5 7 9 11 14 23 27
2 AC DAUs
2 DDAUs
Positive-sequence system/
process values
15 18 22 29 37 44 73 88
2 AC DAUs
1 DDAU
1 BDAU
Phasors /
process values /
binary values
20 24 30 40 50 60 99 119
