Siemens SIMOCODE pro User Manual

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
115
TripNo
Text
25
Thermistor trip level
26 Thermistor short circuit
27
Thermistor open circuit
28 TM1 level T >
29
TM1 sensor fault
30
TM1 out of range
31
Level I >
32
Level I <
33
Level P >
34
Level P <
35
Level Cos-Phi <
36
Level U <
37
AM1 Level 0/4-20mA >
38
AM1 Level 0/4-20mA <
39
Stalled rotor
40
Number of starts >
41
External fault 1
42
External fault 2
43
External fault 3
44
External fault 4
45
External fault 5
46
External fault 6
47 AM1 open circuit
48
Test shutdown
49 DM-F safety-oriented tripping
50
DM-F wiring
51
DM-FL cross circuit
Expanded diagnostics for PROFINET devices:
52
TM2 level T >
53
TM2 sensor fault
54
TM2 out of range
55
AM2 level 0/4-20mA >
56
AM2 level 0/4-20mA <
57
AM2 open circuit
58
EM open circuit
59
EM short circuit

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
