Siemens SIMOCODE pro User Manual

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
142 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Bit assignment Diag_Evt
Table 4- 54 Bit assignment Diag_Evt for SIMOCODE pro PROFIBUS devices
Auxiliary variables
Diag_Evt
bit
Event
Diag_Evt
0
Overload operation
1 Unbalance
2
Overload
3
Overload + phase failure
4
Internal ground fault
5
External ground fault
6
Warning external ground fault
7
Thermistor overload
8
Thermistor short circuit
9
Thermistor open circuit
10
TM warning T>
11
TM trip T>
12
TM sensor fault
13
TM Out of Range
14
Warning I>
15
Warning I<
16
Warning P>
17
Warning P<
18
Warning cos phi<
19
Warning U<
20
Warning 0/4–20 mA>
21
Warning 0/4–20 mA<
22 Trip level I>
23
Trip level I<
24 Trip level P>
25
Trip level P<
26
Trip level Cos-Phi<
27
Trip level U<
28
Trip level 0/4–20 mA>
29
Trip level 0/4–20 mA<
30
Stalled rotor
31
No start permitted
32
No. of starts >
33
Just one start possible
34
Motor operating hours >
35
Stop time >
36
Limit 1
37
Limit 2

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
