Siemens SIMOCODE pro User Manual

Description of the blocks
4.5 Block for statistical function MMStat
SIMOCODE pro PCS 7 Library V9.0
180 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
①
Display of the mode and button for switching between modes
②
Operating hours (D_OpH, M_OpH, M_IntOpH)
③
Number of starts, number of starts "clockwise," number of starts "counterclockwise"
(
N_Strt, N_IntCwStrt, N_IntCcwStrt)
Permissible starts (
P_Strt)
Motor stop time (M_StpTm)
④
Consumed energy in KWh (EngyCon)
Number of parameterizations (
N_Param)
Number of overload trips (
N_OvlTrp)
Number of internal overload trips (N_IntOvlTrp)
⑤
Time until test required (TmTstReq)
⑥
Button for updating the data (RdDataOp). Button is deactivated if RackF_Act = 1; authoriza-
tion level 5 and higher
⑦
Last successfull Timestamp of Read Data
⑧
Navigation button
Navigation to the connected MMOperation block.
Note
The consumed energy parameter is enabled when a vo
ltage module is configured.

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
