Siemens SIMOCODE pro User Manual

Description of the blocks
4.6 Block for timestamping MMLog
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
191
Message block MsgEvId2
The following messages are generated:
Table 4- 89 Output messages
Message block
Message No.
Block parameters
Message text
Message class
MsgEvId2
1
SarMsgEff2[1]
$$BlockComment$$ Signal 1
S
2
SarMsgEff2[2]
$$BlockComment$$ Signal 2 S
3
SarMsgEff2[3]
$$BlockComment$$ Signal 3
S
4
SarMsgEff2[4]
$$BlockComment$$ Signal 4
S
5
SarMsgEff2[5]
$$BlockComment$$ Signal 5
S
6
SarMsgEff2[6]
$$BlockComment$$ Signal 6
S
7
SarMsgEff2[7]
$$BlockComment$$ Signal 7
S
8
SarMsgEff2[8]
$$BlockComment$$ Signal 8
S
* S = AS, OS process control fault
Table 4- 90 Structure of the auxiliary values ALARM_8P
Message No.
Auxiliary
value
Block parameters
Meaning
1
1
SarrTimeStamp[1]
Timestamp array value signal message
2
2
SarrBatchName
Name of batch
3
3
SdwStepNoLoc
Step number
4
4
SdwBatchId
Identification number of the batch
5
5
ExtVa205
External value 5, user-definable
6
6
ExtVa206
External value 6, user-definable
7
7
ExtVa207
External value 7, user-definable
8
8
ExtVa208
External value 8, user-definable
9
9
ExtVa209
External value 9, user-definable
10
10
ExtVa210
External value 10, user-definable
The MsgStat1, MsgAckn1, and MsgErr1 parameters transfer the following information:
● Message status
● Message error
● Message acknowledgment status
Parameters
SigMsg1 to SigMsg8 are messages that can be defined by the user via
SIMOCODE ES or EDD.
