Parameter
A.3 Block parameter MMOprtn
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
249
Parameter
Data format
Default setting
Meaning
AM2InRng STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Analog module 2 – Measuring range input
GrpErr STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Group error is active
OutIn01
WORD
16#00
Process Image input PZDIn01
OutIn23
WORD
16#00
Process Image input PZDIn23
DevFunc
DWORD
16#FF
SIMOCODE device functions
ModlAct
WORD
16#00
Active temperature and analog modules / sensors
DiagStn
DWORD
16#00
SIMOCODE pro PROFIBUS DP station diagnostics
DiagSts
DWORD
16#00
SIMOCODE pro Status Diagnostics
DiagEvt1
DWORD
16#00
SIMOCODE pro Event Diagnostics 1
DiagEvt2
DWORD
16#00
SIMOCODE pro Event Diagnostics 2
DiagEvt3
DWORD
16#00
SIMOCODE pro Event Diagnostics 3
DiagWrn1
DWORD
16#00
Simocode pro Warning Diagnostics 1
DiagWrn2
DWORD
16#00
SIMOCODE pro Warning Diagnostics 2
DiagTrp1
DWORD
16#00
SIMOCODE pro Trip Diagnostics 1
DiagTrp2
DWORD
16#00
SIMOCODE pro Trip Diagnostics 2
TrpNo
INT
0
Trip diagnostic number
WrngNo
INT
0
Warning diagnostic number
CtrlFunc
DWORD
16#00
SIMOCODE pro control function
ParErrNum
BYTE
16#00
Parameter error number
LmtHyst INT 5 Limit monitor - Hysteresis for limit monitors current
0 to 15
CstOn STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Test (CST)
EmrgStOn STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Emergency start
TrpRstOn STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Trip reset
LocalAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Local mode on
AutAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Auto
Automatic Mode Indicator
