Parameter
A.5 Block parameter MMStat
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
261
Block parameters
Data format
Default setting
Meaning
RstEnrgyLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
input 0->1 = Reset Energy consumed
OnOp BOOL FALSE 1 = On Mode: On Mode by Operator
OosOp
BOOL
FALSE
1 = Oos Mode: Oos Mode by Operator
OosLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
input 0->1 = Oos Mode: Oos Mode by Field Signal
SampleTime
REAL
0.1
Sampling Time [s]
RunUpCyc INT 3 Number of cycles for which all messages are sup-
pressed
MsgEvId1
DWORD
16#FF
Message Event ID 1
MsgLock STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Inhibit process message
ExtMsg1 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 1
ExtMsg2 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 2
ExtMsg3 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 3
ExtMsg4 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 4
ExtMsg5 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 5
ExtMsg6 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 6
ExtMsg7 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 7
ExtMsg8 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
External message 8
