Siemens SIMOCODE pro User Manual

Parameter
A.6 Block parameter MMLog
SIMOCODE pro PCS 7 Library V9.0
272 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
SigMsg6 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 6
SigMsg7 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 7
SigMsg8 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 8
MsgErr1 BOOL FALSE 1 = Messaging Error Occurs ALARM_8P1
MsgErr2
BOOL
FALSE
1 = Messaging Error Occurs ALARM_8P2
MsgStat1
WORD
16#00
ALARM_8P1: Status Output
MsgStat2
WORD
16#00
ALARM_8P2: Status Output
MsgAckn1
WORD
16#00
ALARM_8P1: ACK_STATE Output
MsgAckn2
WORD
16#00
ALARM_8P2: ACK_STATE Output
ErrorNum
INT
1
Error Number
ReserveOut
WORD
16#00
Reserved
Structure of OMODE
Table A- 21 Structure of OMODE – MMLog
Bytes
Value
Meaning
Byte 3 16#80:
16#40:
16#20:
Valid data
Invalid data
Redundancy error
Irrelevant
Byte 2
16#01:
Warm restart (OB100)
–
Byte 1; 0
16#0000
–
Irrelevant

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
