Parameter
A.6 Block parameter MMLog
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
271
Parameter
Data format
Default setting
Meaning
OosAct STRUCT
• Value:
BOOL
• ST: BYTE
–
• 1
• 16#80
Out of service is active
MsgSup STRUCT
• Value:
BOOL
• ST: BYTE
–
• 1
• 16#80
1 = Message Suppression Active
ST_Worst
BYTE
16#80
Worst Signal Status
Status1 DWORD 16#00000000 Status1 Word
LogId1 ...
LogId21
INT 0 Logging message ID number 1 to 21
LogTm1 ...
LogTm21
DWORD 16#00000000 Loging time 1 to 21
EnCktCls
INT
0
Enabling ciruit closed ID number
ClsTmStmp
DWORD
16#00000000
Enabling ciruit closed NTP Time Stamp
EnCktOpn
INT
0
Enabling ciruit open ID number
OpnTmStmp
DWORD
16#00000000
Enabling ciruit Open NTP Time Stamp
OS_PermOut
DWORD
16#FFFFFFFF
Operator Permission: Output for OS
OS_PermLog
DWORD
16#FFFFFFFF
Display of OS_Perm with settings changed by block algorithm
OpSt_Out
DWORD
16#FFFFFFFF
Enabled operator stations
SigMsg1 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 1
SigMsg2 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 2
SigMsg3 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 3
SigMsg4 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 4
SigMsg5 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 5
