A.7 Block parameter MMRevDhl
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
277
Parameter
Data format
Default setting
Meaning
FFwdChnST STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Output channel state of Fast Forward
FRevChnST STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Output channel state of Fast Reverse
MsgLock STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Inhibit process message
SampleTime REAL 0.1 Sampling Time [s]
SimLiOp STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Simulation on/off via:
0 = Operator
1 = Interconnection or SFC
SimOnLi STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
1 = Simulation activated by interconnection or SFC (con-
trolled by SimLiOp = 1)
SimOn
BOOL
FALSE
Simulation On/Off
RunUpCyc
INT
3
Number of cycles for which all messages are suppressed
MsgEvId1
DWORD
16#00
Message Event ID 1
MsgEvId2
DWORD
16#00
Message Event ID 2
BatchEn
BOOL
FALSE
Enable Remote Operation of Controller by Batch Recipe
Occupied
BOOL
FALSE
Occupied by Batch
BatchID
DWORD
16#00
Current Batch ID (number)
BatchName
STRING[32]
–
Current Batch Name
StepNo
DWORD
16#00
Batch step number
CSF STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Control System Fault Message - External Error
ExtMsg1 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 1
ExtMsg2 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 2
ExtMsg3 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 3
