Parameter
A.7 Block parameter MMRevDhl
SIMOCODE pro PCS 7 Library V9.0
278 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
ExtMsg4 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 4
ExtMsg5 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 5
ExtMsg6 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 6
ExtMsg7 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 7
ExtMsg8 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 8
ExtMsg9 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 9
ExtMsg10 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 10
ExtMsg11 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
External Message 11
ExtVa104
ANY
–
External Value 104
ExtVa105
ANY
–
External Value 105
ExtVa106
ANY
–
External Value 106
ExtVa107
ANY
–
External Value 107
ExtVa108
ANY
–
External Value 108
ExtVa204
ANY
–
External Value 204
ExtVa205
ANY
–
External Value 205
ExtVa206
ANY
–
External Value 206
ExtVa207
ANY
–
External Value 207
ExtVa208
ANY
–
External Value 208
UserStatus
BYTE
16#00
User Status Bits
SelFp1
ANY
–
Select Faceplate 1
SelFp2
ANY
–
Select Faceplate 2
SelMeas
ANY
–
Select Measurement Faceplate
SelStat ANY – Select Statistic Faceplate
