1.8 Parameterization softwares
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
33
Parameter settings
SIMOCODE pro requires that some parameters have specific settings to ensure correct
operation of the signal blocks:
● Parameters that define the assignment of the cyclic I/O interface. These parameters are
shown in
italics in the following overview.
● Parameters that are already preset in the templates for application selection in
SIMOCODE ES for the control function (*).
General settings (valid for all control functions)
Device parameters → Bus parameters
Diagnosis triggered by device fault
Active
—
Diagnosis triggered by process faults Active —
Diagnosis triggered by process warnings
Active
—
* Diagnosis triggered by process mes-
sages
Not active —
Startup parameter block Active Configuration with SIMOCODE ES or
SIMATIC PDM
Standard functions → Test/reset
Test 1
Cyclic receive bit 0.3
—
Reset 1
Cyclic receive bit 0.6
—
Emergency start
Cyclic receive bit 0.4
—
The settings are a suggestion. They depend on the actual wiring of the SIMOCODE pro
inputs and outputs.
Settings for other parameters are required, for example, for motor protection. These are not
described here.
