Block icons and faceplate views
3.1 Block icons
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
57
The MMRevDhl block provides 2 block icons.
Table 3- 1 MMRevDhl block icons
1
2
The MMOprtn block provides the following block icons:
Table 3- 2 MMOprtn block icons
SIMOCODE pro control function
Overload relay
Direct starter /
PROFIBUS
PROFINET
Reversing starter /
Star-delta reversing starter
Dahlander /
Dahlander reversing starter /
Pole-changing reversing starter
Positioners 1-5
The status display at the block icon depends upon the final status of the drive, but not on the
feedback received from the drive.
