6.2 Function overview and settings
6-155
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
OFF: Ready signal (X111 ready relay)
For S1.2 = OFF, the relay pulls–in if the following conditions are fulfilled:
– Internal main contactor CLOSED (terminals NS1 – NS2 connected, ter-
minal 48 enabled)
– Terminals 63, 64 = ON
– No fault present (also not at the FD 611 A Standard, 611 U,
resolver and 611 D drives and HLA modules).
– FD with High Standard or resolver for the setting ”ready” is enabled (ter-
minals 663, 65)
– For 840D/810D, the NCU must have run–up
ON: Fault signal (X111 ready relay)
For S1.2 = ON, the relay picks up if the following conditions are fulfilled:
– Internal main contactor CLOSED (terminals NS1 – NS2 connected, ter-
minal 48 enabled)
– No fault present (also not at the FD 611 A Standard, 611 U,
resolver and 611 D drives and HLA modules).
– FD with High Standard or resolver for the setting ”ready” is enabled (ter-
minals 663, 65)
– For 840D and 810D the NCU must have run–up
OFF: Standard setting, regenerative feedback into the line supply active
I/R modules 16 kW to 120 kW are capable of regenerative feedback.
UI module: 5 kW, 10 kW, 28 kW: The pulsed resistor in the module
is effective and active.
ON: Regenerative feedback to the line supply is switched off
I/R modules: 16 kW to 120 kW: Regenerative feedback mode is
disabled
UI module: 5 kW, 10 kW: The pulsed resistor in the module is
not active
Valid for
UI 5 kW, Order No.: 6SN1146–1AB00–0BA1 and
UI 10 kW, Order No.: 6SN1145–1AA01–0AA1
Not valid for UI 28 kW. In this case, the external
pulsed resistor must be disconnected.
OFF: Standard setting for all NE modules, refer to S 1.1
ON: V
line
= 480 V +6% / –10%; V
DC
link
= V
line
1.35 in infeed mode
V
DC
link
= 700 to 750 V 2.5% in regenerative feedback mode
Monitoring thresholds: (I/R, UI, monitoring modules)
PR on = 744 V 2.5%; PR off = 718 V 2.5%
V
DC
link
795 V 2.5%
S1.4 exceeds the setting of S1.1
Please note! Unregulated operation in the infeed direction.
!
Warning
For operation with 480 V line supply applications it must be absolutely ensured
that before the line supply is connected, the switch setting S1.4 = ON. If this is
not the case, the infeed circuit in the NE module will be overloaded and
destroyed.
Note
S1.4 ON overwrites the functions of S1.5 and S1.1.
Switch S1.2
Switch S1.3
Switch S1.4
