Siemens SIMODRIVE 611 digital - Page 181

6
05.01
6.7 DC link options
6-181
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
Central
capacitor module
Width = 100 mm
or
Width = 300 mm
PE
LED ”READY”
Status display
is lit from V
DC link
> 300 V
Equipment bus
(equipment bus
cable is included in
the scope of supply)
DClink
P600
M600
Mounting
brackets
Fig. 6-15 Central capacitor module 4.1 mF
6 Infeed Modules11.05
