Siemens SIMODRIVE 611 digital - Page 182

6
05.01
6.7 DC link options
6-182
© Siemens AG 2008 All Rights Reserved
SIMODRIVE 611 Configuration Manual (PJU) – 05/2008 Edition
LED ”READY”
Status display
is lit from V
DC link
> 300 V
Distributed
capacitor module
Width = 100 mm
Connecting terminals
Mounting
position
Fig. 6-16 Distributed capacitor module, 2.8 mF/4.1 mF
6 Infeed Modules 11.05
