3
3.3 Parameterizing using the parameterizing and start–up tool SimoCom U
3-113
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
MPI
or
CP 5511
or
CP 5611
or
CP 5613
(from SW 4.1)
or
OPC server
(from SW 6.1)
”DP slave 611U”
Assumptions:
2–axis board
P0918 (node address) = 15
PROFIBUS–DP
SIMATIC S7–300 (CPU: S7–315–2–DP)
”DP slave 611U”
Assumptions:
1–axis board
P0918 (node address) = 16
”DP slave 611U”
Assumptions:
2–axis board
P0918 (node address) = 17
ÄÄ
ÄÄ
X423 X423 X423
Parameterizing
and start–up tool
”SimoCom U”
PG/PC
Setup.exe
PROFIBUS card
Fig. 3-11 SimoCom U via PROFIBUS (example with 3 control boards)

Example:
SimoCom U via
PROFIBUS–DP
3 Parameterizing the Board
01.99
08.02
