2.2 Connecting–up
2.2.1 General information on connecting–up
Reader’s note
Information on the subjects
 Cabinet design
 Basic rules regarding electromagnetic compatibility (basic EMC
rules)
 Potential bonding
 Cable routing
 EMC–compliant wiring
 Shielding and shield connections
 Handling modules that can be damaged by electrostatic discharge
(ESDS measures), etc.
are included in
Reference: /EMV/ EMC Guidelines, Configuration Manual
!
Warning
Cable shields and cores/conductors of power cables which are not
used (e.g. brake conductors) must be connected to PE potential in
order to discharge charges arising from capacitive coupling.
Hazardous voltages can occur if this is not observed.
