1
1.4 ”SIMODRIVE 611 universal E” control board
1-55
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
1.4.5 What are the differences with respect to ”SIMODRIVE 611 universal”?
Table 1-8 Differences with respect to ”SIMODRIVE 611 universal”
Differ-
SIMODRIVE This should be observed for
SIMODRIVE 611 universal E
611 universal 611 universal E
SIMODRIVE 611 universal E
The
informa-
tion in
this doc-
ument
The following
chapter is of no
significance:
Chapter 1.4
Note for the reader:
Before the 10.99 Edition (SW 3.1) the following was valid:
This documentation only contains information for ”SIMODRIVE 611 univer-
sal”.
From the 10.00 Edition (SW 3.1) the following is valid:
This documentation contains information for ”SIMODRIVE 611 universal”
and ”SIMODRIVE 611 universal E”.
The information for ”SIMODRIVE 611 universal E” is provided in this
Chapter.
The following abbreviations have been introduced to identify the informa-
tion for both modules in the other chapters:
Board Abbreviation (only for this purpose)
SIMODRIVE 611 universal 611u
SIMODRIVE 611 universal E 611ue
The following applies for users of ”SIMODRIVE 611 universal E”:
The Chapter and pages are coded for the reader as follows in the header
line below the edition:
Designation Significance
none Information is valid for 611u and 611ue
! not 611u ! Information is not valid for 611u
! not 611ue ! Information is not valid for 611ue
! 611ue diff ! Information differs between 611u and 611ue.
In addition, this list of differences must be
carefully observed.
Oper-
ating
mode
Speed/
torque set-
point
Speed/
torque set-
point
Permissible settings are:
– P0700 = 0 (the drive is inactive, only drive B)
Thus, a double–axis module can only be oper-
ated as single–axis module.
Should communications be established with inac-
Positioning no
Should communications be established with inac-
tive drive B via PROFIBUS?
If yes, then communications must be disabled
with P0875 = 0.
– P0700 = 1
(operating mode ”speed/torque setpoint”)
P0700 = 3 is not permissible
Memory
module
... for n–set
... for pos
... for n–set The rear of the memory module is identified as follows:
URL.–SOFTWARE N_SOLL–611U (before SW 4.2)
SYS.–SOFTWARE N_SOLL–611U (from SW 4.2)
05.00
