5
5.7 Settings at the PROFIBUS DP master
5-281
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
5.7 Settings at the PROFIBUS DP master
5.7.1 Master device file and configuring
PROFIBUS devices have different performance features.
In order that all of the master systems can correctly address the ”DP
slave 611U”, the characteristic features of the slave are combined in a
standardized master device file (GSD).
The ”DP slave 611U” is exclusively operated as DP slave.
The following master device files (GSDs) are available for the ”DP
slave 611U”:
Before SW 4.1:
SIEM8055.GSD for the optional PROFIBUS–DP1 module
SIEM808F.GSD for the optional PROFIBUS–DP2 and DP3 modules
From SW 4.1:
SIEM808F.GSD for the optional PROFIBUS–DP2 and DP3 modules
From SW 6.1:
SIEM808F.GSD for the optional PROFIBUS DP2 and DP3 modules
(PROFIdrive application Class 1)
SI02808F.GSD for the optional PROFIBUS DP2 and DP3 modules
(PROFIdrive application Class 4)
Using the GSD file SI02808F.GSD, it is no longer necessary to enter
the block for clock–cycle synchronism into the parameterizing tele-
gram manually byte–for–byte.
In order to use the GSD file SI02808F.GSD, a configuring tool is
required which supports the GSD Revision 4 (e.g. Step7 HW–Config
Version x.xx)
Reader’s note
From SW 4.1, the optional PROFIBUS–DP1 module can no longer be
used.
Compatibility conditions, GSD file and optional modules are described
in Chapter 1.3.3 in Table 1-4.
The GSDs are available as ASCII files on the data medium (e.g. CD)
for ”SIMODRIVE 611 universal”.
These files uniquely describe the features and properties of the ”DP
slave 611U” in a precisely defined format.
The GSD file must be inserted into the configuring tool of the master.
Performance
features of
the PROFIBUS
devices
Master device file
for
”DP slave 611U”
5 Communications via PROFIBUS DP
08.02
