6.5 Input/output terminals for the optional TERMINAL module
6-526
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
6.5 Input/output terminals for the optional TERMINAL module
An optional TERMINAL module has 8 input and 8 output terminals,
which can be freely parameterized (refer to Chapter 1.3.3).
A terminal is assigned any function by entering the function number
corresponding to the required function into the parameter assigned to
the terminal.
Notice
The terminals may only be parameterized when the drive pulses are
canceled.
The following assignment exists between the input/output terminals,
drives and parameters:
Table 6-50 Terminals and parameters for the optional TERMINAL module
Terminals
Parameters
Drive A/B No. Name Min. Stan-
dard
Max. Units Effec-
tive
Input terminals
I4 X422.1 0664 Function, input terminal I4 0 60 82 – Immed.
I5 X422.2 0665 Function, input terminal I5 0 59 82 – Immed.
I6 X422.3 0666 Function, input terminal I6 0 58 82 – Immed.
I7 X422.4 0667 Function, input terminal I7 0 50 82 – Immed.
I8 X422.5 0668 Function, input terminal I8 0 51 82 – Immed.
I9 X422.6 0669 Function, input terminal I9 0 52 82 – Immed.
I10 X422.7 0670 Function, input terminal I10 0 53 82 – Immed.
I11 X422.8 0671 Function, input terminal I11 0 54 82 – Immed.
Output terminals
O4 X432.1 0684 Signaling function
output terminal O4
0 72 82 – Immed.
O5 X432.2 0685 Signaling function
output terminal O5
0 60 82 – Immed.
O6 X432.3 0686 Signaling function
output terminal O6
0 62 82 – Immed.
O7 X432.4 0687 Signaling function
output terminal O7
0 50 82 – Immed.
O8 X432.5 0688 Signaling function
output terminal O8
0 51 82 – Immed.
Description
Overview of the
terminals and
parameters
