4.6 Parameters for hardware, operating mode and clock cycles
4-138
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Power module (Order No.) Automatic identification?
 6SN112––0 No automatic identification
 from 6SN112––1 Automatic identification
: Space retainer for the Order No.
After the first commissioning, a value is in P1106 (power module code
No.) which corresponds to the particular power module.
An automatic power module identification routine is executed each time
the control board runs up. In this case, the value in P1106 is compared
with the value of the power module identified in P1110.
If the values are not the same, there is an error condition, and an ap-
propriate fault message is signaled.
Table 4-4 Hardware parameters
Parameters
No. Name Min. Standard Max. Units Effective
1102 Motor code number 0 0 FFFF – PO
The motor code number defines the connected motor.
Note:
 The motor code of the existing motor is located in the following lists:
– for rotating synchronous motors (SRM) ––> refer to Chapter A.3.1
– for permanent–magnet synchronous motors with field–
weakening (1FE1 motor, PE spindle, from SW 3.1) ––> refer to Chapter A.3.2
– for linear synchronous motors (SLM) ––> refer to Chapter A.3.4
– for induction motors (ARM) ––> refer to Chapter A.3.5
 At the first commissioning and at each POWER ON, the motor data are pre–assigned
according to the entered motor code (Exception: unlisted motor).
 For unlisted motors, the parameters must be manually assigned (refer to Chapter A.3).
1106 Power module code number 0 0 FFFF – PO
The power module code number defines the power module used.
Note:
 The power module code can be determined from a list (refer to Chapter A.2).
 It is not necessary to select power modules with automatic identification.
1006 IM encoder code number 0 0 65 535 – PO
The encoder code number describes the connected encoders.
Note:
 The encoder code number can be determined from a list (refer to Chapter A.4).
 At the first commissioning and at each POWER ON the encoder data are pre–assigned
corresponding to the entered encoder code number (Exception: Unlisted encoder).
 For unlisted encoders, the parameters must be manually assigned (refer to Chapter A.4).
