4.7 Induction motor operation with induction motor
4-145
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
START
Power–up the unit
(power ON)
Is
” _ _ _ r u n ”
displayed
?
– Connect–up the unit
– Check the connections
Request a new
commissioning?
Already
commissioned?
no
Is either
A1106 or b1106
displayed?
no
yes
yes
yes
no
yes
no
– Remove write protection (P0651 = 4)
– Boot, set P0659 to 0
– Start to write into the FEPROM (P0652 = 1) and
then wait until the write operation has been
completed (P0652 = 0)
– Carry–out a HW power–on reset
or power off ON
Establish the boot state
Carry–out the hardware configuration
(parameter list, refer to Chapter A.1)
1)
only if not
automatically
identified
1
– Enter the power module code
number
1)
(P1106)
– Enter the motor code number
(P1102 = 99)
– Enter the encoder code number
(P1006 = 98, no encoder)
– Define the operating mode (P0700)
– Boot
(set P0659 to 1)
continue on the next
page
End
(cyclic operation)
2
2
Is the ”E– ...”
displayed flashing
or
is the display inactive?
Remove the cause!
(refer to Chapter 7.3)
Fault message ”E–x683” is displayed.
Using the – key, change from the alarm
mode into the operating mode (repeat
often, as the system automatically
changes over into the alarm mode after 1
minute).
Fig. 4-7 Commissioning induction motors without encoder (Part 1)
Commissioning,
induction motors
without encoder
To Next Page
