4.10 Linear motors (1FN1, 1FN3 motors)
4-190
Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
The temperature sensor coupling cable is used to couple the tempera-
ture sensor circuit Temp–F into the encoder cable using connector bo-
xes. The transition from the power cable to encoder cable can be reali-
zed at the machine as well as in the cabinet.
Please refer to the following note for the reader
Reader’s note
Section ”General information on the connection system (CON)” in:
Reference: /PJLM/ Configuration Manual,
1FN1, 1FN3 Linear Motors
If an incremental measuring system is used, the drive is roughly syn-
chronized using the rotor position identification.
!
Warning
When connecting–up the temperature monitoring circuits, carefully
observe the specifications relating to protective separation
DIN EN 50178.
Information on protective separation can be taken from:
Reference: /PJLM/ Configuration Manual,
1FN1, 1FN3 Linear Motors
Temperature
sensor coupling
cable
How are the
temperature sensor
coupling cable and
length measuring
system connected?
