5.6 Net data (PKW and PZD area)
5-222
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Table 5-7 Control word STW2
STW
2
Motor data changeover 1st input (from SW 2.4)
1)
Motor data changeover 1st input (from SW 2.4)
1)
Motor changed over (from SW 2.4)
1)
Suppress fault 608 (from SW 3.1)
Master sign–of–life (from SW 3.1)
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Selection, parking axis
Integrator inhibit, speed controller
Bit 2
Bit 1
Bit 0
Parameter set changeover
Reserved
Ramp–up time zero
First speed setpoint filter off
Note:
The control signals, from the perspective of ”SIMODRIVE 611 universal”, are input signals and are
described in Chapter 6.4.3.
Also refer in the index under ”Input signal, digital ...”).
1) Only available in the n–set mode
Control word
STW2
5 Communications via PROFIBUS DP
08.99
10.99
