5
5.6 Net data (PKW and PZD area)
5-247
 Siemens AG 2005 All Rights Reserved
SIMODRIVE 611 universal Description of Functions (FBU) – 04.05 Edition
Assumptions for the example:
 Measuring probe with a positive edge (function 1)
 Closed–loop position control with encoder 1
Mode
G1_STW.7 = 1
Function 1
G1_STW.0 = 1
Command
G1_STW.4 = 1
(activate function)
G1_STW.5 = 1
(read value)
Function active
G1_ZSW.0 = 1
Value available
G1_ZSW.4 = 1
Measuring probe
deflected
G1_ZSW.8
Measuring probe edge
Actual value transfer
1
0
1
0
1
0
1
0
1
0
1
0
1
0
Flying measurement
Measuring probe, positive edge
Activate function 1
Function 1 active
Value 1 available
1)
1) Signal must be reset by user
1
0
Read value 1
Fig. 5-15 Function chart for ”flying measurement”
Example 2:
Flying
measurement
5 Communications via PROFIBUS DP
08.99
05.0002.02
